Hammer Driver Drill XGT®

HP001G

Next Generation Hammer Driver Drill

Hammer Driver Drill XGT® 40V Max

The HP001G is an efficient and powerful brushless Hammer Driver Drill for both screwdriving and drilling. Featuring two different power settings it has been specifically designed with professional users in mind. A high maximum torque of 140 / 68 Nm makes this machine the ideal choice for jobs that require high power and torque and the hammer function also allows it to be used across a wide range of applications.

Excellent Performance In Continuous Heavy Duty Applications!

The XGT® tools and batteries come with a built-in program, providing digital communication between the battery and tool. Allowing not only for the battery to communicate with tool but also the tool to communicate to the battery. The battery also recognizes and stores which tool are used. HP001G has a powerful brushless motor with a long runtime.

HP001G has 41 electronical clutch settings with an easy jog dial adjustment and digital display allowing for a wider range of torque to be  reached with with a mechanical clutch. AFT technology also prevents possible injuries by turning off the motor if bit rotation is suddenly forced to stop.

High Drilling Speed And Efficient Work

Work amount on a full BL4025 (2.5Ah) battery charge

About 40 pcs of Drove ø8 x 400mm long construction screws into 400mm thick SPF

About 90pcs of Drilled holes through 38mm thick SPF with ø65mm (2 - 9/16") self-feeding bit

About 480 pcs of Drilled holes through 38mm thick SPF with 7/8" Ship Auger bit

Hammer Driver Drill XGT® 40V Max

Efficient and durable brushless Hammer Driver Drill with high drilling speed and solid performance for professional use. The machine features a mechanical 2-speed dial, Active Feedback sensing Technology, a LED job light and a max torque of over 140 Nm.

FEATURES AND TECHNICAL DATA

Features

1. Mechanical 2- speed switch.

2. Solid performance especially in heavy duty applications thanks to the efficient brushless motor and XGT® battery.

3. LED job light.

4. Active Feedback sensing Technology: Turns the motor off if bit rotation is suddenly forced to stop.

5. 41 electronical clutch setting (21-stage setting in High mode). A higher range of torque can be covered than with mechanical clutch.

Technical Specifications

Capacity: Steel: 20 mm / Wood (Auger-Bit): 50 mm
Wood (Self-Feed Bit): 76 mm / Wood (Hole Saw): 152 mm
Masonry: 20 mm

Impacts Per Minute (IPM): High / Low: 0 - 39,000 / 0 - 9,750

Chuck Capacity: 1.5 - 13 mm

No Load Speed (RPM): High / Low: 0 - 2,600 / 0 - 650

Max Fastening Torque: Hard / Soft: 140 / 68 N·m

Max lock torque: 125 N·m

Sound Pressure Level: 85 dB(A)

Sound Power Level: 96 dB(A)

Dimensions (L x W x H):

w/ BL4025: 181x86x275 mm
w/ BL4040: 181x86x282 mm

Weight with battery: 2.7 - 3,0 kg

Available Versions

HP001GZ

Tool only, battery and charger not included

Press release

A powerful, brushless drill for professional screwdriving and drilling with or without hammer action, two power settings. A high maximum torque of 140 / 68 Nm. An ideal choice for jobs that require high power and torque. Integrated LED light.
