Earth Auger XGT®
DG001G40Vmax • 0 – 1 500 min⁻¹ • 55 / 136 Nm
XGT® battery powered brushless earth auger for drilling holes in the ground
DG001 is a powerful and lightweight brushless earth auger for drilling holes to the ground. Equipped with 2-speed options (0 - 400 min⁻¹ & 0 - 1 500 min⁻¹) and reverse. Max fastening torque (High / Low) is 55 / 136 Nm. Twin led lights illuminates the working area.
- Available version(s)
- General
- Technical info
- Related Products
- Parts diagram
- Dust Extraction
- Additional info
- Support
Available version(s)
1 Available version
DG001GZ05
Earth Auger XGT®
XGT® battery powered brushless earth auger for drilling holes in the ground
General
User benefits
- Brushless maintenance-free and long-life motor
- Variable 2-speed options allows the user to match speed to application
- Twin LED job light with pre-glow and afterglow functions illuminates the work area
- Soft start for smooth start-ups
- eXtreme Protection Technology (XPT) is engineered for improved dust and water resistance for operation in harsh conditions
Technical info
Technical specifications
-
Voltage XGT
-
Nominal Battery Voltage40 V
-
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion)Li-ion
-
Brushless Motor
-
Max Output Power1350 W
-
No load speed0 - 400 / 0 - 1500 min⁻¹
-
Max. Torque (2. Gear / 1. Gear)55 / 136 Nm
-
Drill Chuck Capacity2 - 13 mm
-
Product Dimensions (L x W x H):842 x 605 x 199 mmProduct dimensions are stated with a battery / batteries, if they affect the overall dimensions of the product.- CXT® machines with 2,0Ah batteries- LXT® machines with 6,0Ah batteries- XGT® machines with 4,0Ah batteries
-
Tool weight with battery7,2 - 8,7 kg
-
Product net weight6,4 kg
-
Vibration Level, Drilling into metal≤ 2,5 m/s²
-
Vibration Uncertainty (K Factor), Drilling into metal1,5 m/s²
-
Sound Power Level (LWA)95 dB(A)
-
Sound Pressure Level (LpA)84 dB(A)
-
Noise Uncertainty (K Factor)3 dB(A)
Symbols:
Variable Speed
Brake
Reversing
Mechanical 2-Speed
Torque limiter
Soft Start
Built-in Job Light
