Rotary Hammer LXT®

Technical specifications

Nominal Battery Voltage
2 x 18 V
Voltage LXT
Brushless Motor
Impact Energy
2,8 J
Optimum Drilling Diameter Range in Concrete
10 - 18 mm
Max. Drilling Diameter in Concrete
28 mm
Max. Drilling Diameter in Wood
32 mm
Max. Drilling Diameter in Steel
13 mm
Impacts per Minute (IPM)
0 - 5000 min⁻¹
No load speed
0 - 980 min⁻¹
Plastic Carrying Case
Sound Power Level (L_WA)
104 dB(A)
Sound Pressure Level (L_pA)
93 dB(A)
Noise Uncertainty (K Factor)
3 dB(A)
Vibration Level, Chiselling
10,8 m/s²
Product Dimensions (L x W x H):
373 x 134 x 232 mm

Product dimensions are stated with a battery / batteries, if they affect the overall dimensions of the product.


- CXT® machines with 2,0Ah batteries
- LXT® machines with 6,0Ah batteries
- XGT® machines with 4,0Ah batteries
Drilling diameter with TCT core bit
54 mm
Adapted for SDS-PLUS bits
Tool weight with battery
3,8 - 4,9 kg
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion)
Li-ion
Electronic brake
Vibration Level, Hammer Drilling Into Concrete
14,5 m/s²
Vibration Uncertainty (K Factor), Hammer Drilling Into Concrete
2,8 m/s²
Vibration Uncertainty (K Factor), Chiselling
1,5 m/s²
