Impact Driver LXT®

Technical specifications

Nominal Battery Voltage
18 V
Voltage LXT
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion)
Li-ion
Brushless Motor
No load speed
0 - 1100 / 2100 / 3200 / 3600 min⁻¹
Max Fastening Torque Impact Drill
20 / 50 / 170 / 180 Nm
Impacts per Minute (IPM)
0 - 1100 / 2600 / 3600 / 3800 min⁻¹
Tightening Capacity Standard Bolt
M5 - M16
Capacity machine screw
M4 - M8
Tightening Capacity High Tensile Bolt
M5 - M14
Driving Shank
1/4 "
Sound Power Level (L_WA)
108 dB(A)
Sound Pressure Level (L_pA)
97 dB(A)
Noise Uncertainty (K Factor)
3 dB(A)
Vibration Level, Impact Tightening of Fasteners of the Maximum Capacity of the Tool
12,9 m/s²
Vibration Uncertainty (K Factor), Impact Tightening of Fasteners of the Maximum Capacity of the Tool
1,5 m/s²
Product Dimensions (L x W x H):
111 x 81 x 234 mm

Product dimensions are stated with a battery / batteries, if they affect the overall dimensions of the product.


- CXT® machines with 2,0Ah batteries
- LXT® machines with 6,0Ah batteries
- XGT® machines with 4,0Ah batteries
Tool weight with battery
1,2 - 1,5 kg
Product net weight
0,85 kg
