Rotary Hammer XGT®

Technical specifications

Brushless Motor
Nominal Battery Voltage
40 V
No load speed
250 - 500 min⁻¹
Impacts per Minute (IPM)
1450 - 2900 min⁻¹
Max. Drilling Diameter in Concrete
40 mm
Optimum Drilling Diameter Range in Concrete
16 - 30 mm
Impact Energy
8,0 J
Drilling diameter with TCT core bit
105 mm
Plastic Carrying Case
Sound Power Level (L_WA)
101 dB(A)
Sound Pressure Level (L_pA)
90 dB(A)
Noise Uncertainty (K Factor)
3 dB(A)
Vibration Level, Chiselling
3,7 m/s²
Tool weight with battery
7,4 - 8,8 kg
Product Dimensions (L x W x H):
500 x 115 x 286 mm

Product dimensions are stated with a battery / batteries, if they affect the overall dimensions of the product.


- CXT® machines with 2,0Ah batteries
- LXT® machines with 6,0Ah batteries
- XGT® machines with 4,0Ah batteries
Voltage XGT
Adapted for SDS-MAX bits
Electronic brake
AWS ready
Vibration Level, Hammer Drilling Into Concrete
4,6 m/s²
Vibration Uncertainty (K Factor), Hammer Drilling Into Concrete
1,5 m/s²
Vibration Uncertainty (K Factor), Chiselling
1,5 m/s²
Product net weight
6,3 kg
