Homepage TOOLS Cordless Tools Cordless Tools (36V) Chainsaws, Hedge Trimmers, and Blowers (36V) Battery Powered Backpack Blower
3 year warranty
  • New
    Battery Powered Backpack Blower

Battery Powered Backpack Blower

UB004C
Model UB004C is a battery powered blower powered by portable power pack PDC1500 or PDC1200
This machine can be operated at a high blowing force of 25N (no time limit), and in Boost mode, it can be operated at blowing force of 28N (with a time limit).

  • High power
  • Variable speed control by trigger + Cruise control lever
  • Three speed mode button
  • Redesigned backpack harness section for more comfortable use.
    • Available version(s)
    • General
    • Technical info
    • Related Products
    • Parts diagram
    • Dust Extraction
    • Additional info
    • Support

    Available version(s)

    1 Available version
    UB004CZ Battery Powered Backpack Blower
    Barcode:
    0197050004529
    Display contents

    General

    Plug-In
    Brushless Motor

    User benefits

    • Max blowing force can be easily obtained by fully pulling the trigger (Boost mode)
    • Variable speed control by trigger, with cruise control lever that allows the user to lock the trigger at desired power level
    • Battery fuel gauge indicates battery charge level
    • eXtreme Protection Technology (XPT) is engineered for improved dust and water resistance for operation in harsh conditions
    • The grip position is adjustable forward/backward and left/right to suit user's size or work posture

    Technical info

    Technical specifications

    • Max. Air Velocity
      33,2 / 59,0 / 76,3 / 80,7 m/s
    • Air volume
      0 - 19,7 / 20,9 m³/min
    • Nominal Battery Voltage
      36 V
    • No load speed
      10500 / 18000 / 22500 / 23800 min⁻¹
    • Sound Power Level (LWA)
      96,1 dB(A)
    • Sound Pressure Level (LpA)
      82,3 dB(A)
    • Noise Uncertainty (K Factor)
      2,0 dB(A)
    • Tool weight with battery
      16,5 - 18,6 kg
    • Battery Chemistry (Ni-Cd / Ni-MH / Li-ion)
      Li-ion
    • Voltage LXT
    • Voltage XGT
    • Blowing force
      5 / 15 / 25 / 28 N
    • Continuous Use PDC1500
      200 / 55 min
    • Vibration Level, No load
      2,5 m/s²
    • Vibration Level, Operation Without load
      ≤ 2,5 m/s²
    • Vibration Uncertainty (K Factor), Operation Without load
      1,5 m/s²
    • Brushless Motor

    Barcode

    Symbols:

    Variable Speed

    Anti-restart function

    Electronic 3-Speed

    Constant speed
